ENEC Certified Economical 30w LED Street Light

Economical 30w LED Street Light, Low-power design is exquisite and compact, the price is affordable, suitable for residential, domestic, and country roads. This design of the street lamp head is also suitable for use as a solar street light system.

Inquire Now Produit suivant

PRODUCT VIDEO

PRODUCT DESCRIPTION

Key Features

● Wide power range: 20W~50W.

● In special circuit design, single LED damage won't affect others' normal work.

● Smart design, low transportation costs.

● A smooth body would greatly diminish dust accumulation and bird droppings heap up.

● High Lumen output up to 160lm/ w with high-quality Lumileds LED chips.

● Multiple lighting control options are available, e.g. 1-10V, photocell.

● Designed to last at least 100, 000 hours at L70.

Specifications

Model	ZGSM-LD30Kmini
LED Brand	LUMILEDS® LUXEON 3030/ 5050
Driver Brand	Inventronics
Normal Wattage	30W
LED Chip Quantity	3030: 40pcs 5050: 16pcs
Input Voltage	100-240/277VAC
Power Efficiency	>90%
Power Factor	>0.95
Lamp Rated Luminous Efficiency	3030: 140 lm /w 5050: 150 lm /w
Lamp Rated Lumen output	3030: 4200 lm 5050: 4500 lm (Lumen tolerance +/- 5%)
Color Rendering Index	70(80 optional)
Color Temperature	3000K, 4000K, 5000K, or 5700K
Photometric Type	3030: Type II Medium 5050: Type II Medium BLS
Optimal Operating Temperature	25℃
Storage Temperatures	-40°C~50°C
Working Environment	Between-40°C~+50°C, 10%~90%RH
Total Harmonic Distortion	< 10%
Lumen Maintenance	> 100,000 hours -L70, @25 ºC (77 ºF)
Wind Index	Force 12
Body and Shell Materials	Die-cast aluminum; PC Lens
Pole Fitter Diameter	60mm ( 50mm optional)
Rating	IP66 IK10
Protection	Class I
SPD	10KV (20KV optional)
Certification	CE, ENEC, CB, ROHS, LM80, LM79, IP66, IK10, ISTMT
Dimming Options	1-10V
Control Options	Photocell or Smart control
Color Options	Deep grey
Warranty	5 years

FAQ

1. What is the voltage of a street light?

The most common street lamp operating voltage is 120 volts (62%), followed by 240 volts (28%). The majority of entities (82%) that own street lights use a separate photocell to control the on/off function of the street light.

2. Which lighting is the most economical for street lighting?

LEDs

LEDs are the most efficient street lighting technology, and their costs are rapidly decreasing, but the cost per luminaire is usually 2-4 times that of traditional high-pressure sodium technology. However, it uses more than 30–50% less energy and significantly reduces energy costs over its lifetime.

3. How efficient are LED street lights?

LED lamps are 40 to 60 percent more energy-efficient than conventional lighting technologies. Simply using LED luminaires, you can provide better lighting, lower energy consumption, and reduced CO2 emissions.
