High cost performance LED Street Light
ZGSM Halo series round LED Street Lights are launched in August 2022. It has an excellent design of 6 mounted ways for your options: single-arm post top mounted, double-arm post top mounted, side entry mounted, pole pendant mounted and wire suspension mounted for your options. With multiple installation ways, Halo series could be applied to street lighting, garden lighting, park lighting, parking lot lighting, country path lighting and so on.
1. Power range 30W up to 150W
2. Super smooth body design
3. Full die-casting aluminum housing
4. Efficiency up to 170 lm / W
5. 10/20KV surge protection, IP66&IK10
6. Supports multiple installation modes
7. Class I and Class II are optional.
8. CE, RoHS, ENEC, CB, LM79, LM80, TM-21, IP66, IK10 certified
9. Kinds of asymmetrical optical lens provide professional light distribution
10. Smart Control: 1-10V/ DALI dimming, NEMA, Zhaga, Photocell, Motion sensor, Zigbee /Lora control
| Model | ZGSM-ST20-XXYY( XX= 30~150W, YY=PT1,PT2,SE,WS,HB,PP) |
| LED Brand | LUMILEDS® LUXEON 3030 or 5050 |
| Driver Brand | Meanwell / Inventronics |
| Normal Wattage | 30W, 50W, 80W, 100W, 120W,150W |
| Mounting Way | Single Arm Post Top, Double Arm Post Top, Side Entry, Wire Suspension, High Bay, Pole Pendant |
| Input Voltage | 100-240/277VAC |
| Power Efficiency | >90% |
| Power Factor | >0.95 |
| Lamp Rated Luminous Efficiency | 145-170 lm/W |
| Standard Deviation of Color Matching | <5 SDCM |
| Color Rendering Index | 70(80 optional) |
| Color Temperature | 3000K or 4000K or 5000K or 5700K |
| Photometric Type | Type II Medium; Type III Medium. |
| Optimal Operating Temperature | 25℃ |
| Storage Temperatures | -40°C~50°C |
| Working Environment | Between-40°C~+50°C, 10%~90%RH |
| Total Harmonic Distortion | < 10% |
| Lumen Maintenance | > 100,000 hours -L70, @25 ºC (77 ºF) |
| Wind Index | Force 12 |
| Body and Shell Materials | Die-cast aluminum; Tempered Glass |
| Pole Fitter Diameter | 60mm |
| Rating | IP66 & IK10 |
| Protection | Class I ( Class II optional) |
| SPD | 10KV (20KV optional) |
| Certification | CE, RoHS, ENEC, CB, LM79, LM80, TM-21, IP66, IK10 |
| Dimming Options | 1-10V or DALI or PWM or Timer |
| Control Options | Photocell or Motion sensor or Smart control |
| Color Options | Gray (RAL9007) /Black (available on request) |
| Warranty | 5 years |
The Rould LED Street Lights is one kind of LED street lights with a round body design, like ZGSM L series and Halo series. It not only have the same advantages of high efficacy, long lifespan, energy saving as other LED street lights. The elegant housing design also makes it could be applied to city street lighting, garden lighting, community Lighting, residential area lighting and so on.
For the design, manufacture, and distribution of products, there are standards that have been established by international and regional standardization bodies like CIE, IES, and CEN that are widely regarded as industry best practices. The LED lights manufacured by ZGSM are CE, RoHS, CB, UL, DLC, SAA, ENEC certified. The lighting solutions we provide meet the requirements of these standard.
LED Street Lights, LED Flood Lights and LED High Mast Lights and other kinds of LED lights, which could be installed on the pole and have wide beam angles, are best for parking lot lighting. Choosing LED lights to replace the old HPS or metal halide lamps could not only help to save energy, but also good to our environment.
